INTRODUCTION
Medical CE approved , US FDA 510K cleared
Making radiant skin appearance
For skin imperfection
As the laser energy is released in a very short time, a giant pulse with a very high peak value is formed. After absorbing the huge laser energy in an instant, the pigment particles rapidly expand and burst, while the cell framework can be completely preserved and repaired. After the pigment particles are broken, they are gradually swallowed by phagocytes and discharged out of the body, resulting in the reduction of the local pigment in the lesion. At the same time, the heat energy generated by the interaction between laser and human tissue is effectively confined to the target tissue, thus avoiding the thermal damage of the surrounding tissue. That is, to achieve therapeutic effects with almost no damage to normal tissue.
Among them, the penetration ability of 1064nm laser to skin tissue is strong, can reach in the deep skin melanocytes, black and blue tattoo color particles, suitable for removing deep pigmentation lesions and dark color tattoos; The energy of the 532nm laser is limited to the surface of the skin, so this wavelength is very effective for the treatment of superficial pigmented nevus, suitable for superficial pigmented lesions and red tattoos.
ADVANTAGE
Our HS-290 is a tattoo removal machine specially offered to suit straight into any tattoo studio, clinic or salon. It is stand passive Q-Switched Nd:YAG Laser will help our customers get idea removal of all different kinds of tattoos.
It is produced with four highly powered Q-Switched Nd:YAG Laser wavelengths to ensure removal of tattoo pigments.
OUR SPECIAL DESIGNED HANDPIECE
The HS-290 handpieces can generate different flat-top spot shapes with special design for uniform beam profile are ideal for tattoo removal, perfect for skin rejuvenation and resurfacing with very fast recovery time.
WITH 2 DIFFERENT operation mode of Professional Mode and Standard mode for frieindly easy operation.
- A9 FAST reaction with A9 Quard-core processor CPU
-USB FUNCTION for updating software simply and automatically.
- IC CARD FUNCTION To control shot number and expiry period to get derivative cooperation ways:
- RENTAL / INSTALLMENT/ Control after service (Handpiece warranty period)
SPECIFICATION
Laser Type | EO Q-switch Nd:YAG laser |
Wavelength | 1064/532nm |
Operate mode | Q-switched mode & SPT mode |
Beam profile | Flat-top mode |
Pulse width | ≤6ns (Q-switched mode) |
300us (SPT mode) | |
Pulse energy | Q-switched 1064 mode: Max. 2000mJ |
Q-switched 532 mode: Max. 800mJ | |
SPT mode (1064nm): Max. 2800mJ | |
Energy calibration | External & self-restoration |
Spot size | 2-10mm |
Repetition rate | Max. 10Hz (1064nm, 532nm, SPT mode) |
Optical delivery | Articulated arm |
Operate interface | 9.7’’ true color touch screen |
Aiming beam | Diode 655nm (Red), brightness adjustable |
Cooling system | Advanced Air & Water cooling system |
Power supply | AC 100V or 230V, 50/60Hz |
Dimension | 82*30*88cm (L*W*H) |
Weight | 80Kgs |
Application:
Apolomed EO Q Switch Nd:YAG laser system, with the advanced pulsed Nd YAG laser technology, could make the skin selectively absorbing certain wavelength of laser and achevie curative effect. The pulsed nd yag laser HS-290 is widely used to:
Melasma
Tattoo removal
Pigment removal
Yag laser skin rejuvenation
