HS-900
Apolomed
INTRODUCTION
The multifunction beauty machine can support 8 different handpieces: 1. IPL: Permanent Hair Removal, Photorejuvenation, Remove Vascular, Pigment and Acne; 2. EPL: Combination IPL and bipolar RF; 3. RF monopolar: Skin Tightening, Weight lossing, Sculpture, Pore Cantracting; 4. RF bipolar: Skin Tightening, Sculpture, Wrinkle Removal, Pore Shrink 5. Q-Switched Nd:Yag laser: Tattoo and pigment removal; 6. 1064nm Long pulse Nd:Yag laser: Permanent Hair Removal for all skin types, Dispel Leg Veins and Vascular lesion; 7. 1540nm Fractional Er:Glass laser: Non-ablative Skin resurfacing, Remove deep winkles and scars; 8. 2940nm Er:Yag laser: Wart and Nevus removal, Skin Resurfacing, Wrinkles and Fine lines.
Application:
1. 8-in-1 multifunction system available,which combine different technoties in one basic unit. 2. Auto-detect interchangeable handpieces for option 3. Excellent cooling system with TEC water tank,Italy pump and high speed fans. 4. Multi-languages supported,meets requiremnets of global market. 5. Friendly touchable operate interface with standard mode and professional mode. 6. Interlock design ensure safety treatment environment. 7. Mudularized design for convenienet maintenance. 8. USB and IC card function supported.
ADVANTAGE
1. 8-in-1 multifunction system available,which combine different technoties in one basic unit.
2. Auto-detect interchangeable handpieces for option
3. Excellent cooling system with TEC water tank,Italy pump and high speed fans.
4. Multi-languages supported,meets requiremnets of global market.
5. Friendly touchable operate interface with standard mode and professional mode.
6. Interlock design ensure safety treatment environment.
7. Mudularized design for convenienet maintenance.
8. USB and IC card function supported.
SPECIFICATION
Technical Specification:
| Model | HS-900 | |
| Power Supply | 100/110V or 230/260V, 50~60HZ | |
| Dimension | 65cm *48cm *115cm( L*W*H) | |
| Weight | 65kgs | |
| Operate Interface | 8" Ture color touch screen TFT LCD | |
| Cooling system | Air & Water & TEC cooling system | |
| IPL | Applications | Permanent Hair Removal, Photorejuvenation, Vascular Lesions, Pigment Lesions, Acne |
| Spectrum | 420-1200 nm | |
| Filters | 420/510/560/610/640nm (Standard); 480/585/690/755 (Optional) | |
| Energy Density | 10-60 Level ( Max. 60J/cm² ) | |
| Pulse Duration | 2-20 ms | |
| Pulse Delay | 5-50 ms | |
| Pulse Characteristic | Multiple-Sequential Pulsing, Up to 15 Pulse | |
| Repetition Rate | 1-4s | |
| Spot Size | 12x35mm (Standard), 12x12mm, 12x50mm, 15x15mm, 15x35mm, 15x50mm(Optional) | |
| E-light (IPL with RF) | Applications | Permanent Hair Removal, Photorejuvenation, Vascular Lesions, Pigment Lesions, Acne |
| Spectrum | 420-1200 nm | |
| Filters | 420/510/560/610/640nm (Standard); 480/585/690/755 (Optional) | |
| Energy Density | 10-60 Level ( Max. 60J/cm² ) | |
| RF Output Power | 200W | |
| Pulse Duration | 2-20 ms | |
| Pulse Delay | 5-50 ms | |
| Pulse Characteristic | Multiple-Sequential Pulsing, Up to 15 Pulse | |
| Repetition Rate | 1-4s | |
| Spot Size | 12x35mm (Standard), 12x12mm, 12x50mm, 15x15mm, 15x35mm, 15x50mm (Optional) | |
| RF-Monopolar | Applications | Skin Tightening, Weight lossing, Sculpture, Pore Cantracting |
| RF Tip | ¢18mm, ¢28mm, ¢37mm | |
| RF Frequency | 1MHz | |
| RF Output Power | 200W | |
| RF-Bipolar | Applications | Skin Tightening, Sculpture, Wrinkle Removal, Pore Shrink |
| RF Tip | ¢18mm, ¢28mm, ¢37mm | |
| RF Frequency | 1MHz | |
| RF Output Power | 200W | |
| Q-Switched ND:YAG Fractional Laser | Applications | Pigmented Nevus, Birthmark, Cholasma, Macula, Telangietasia, Skin Rejuvenation |
| Spectrum | 1064nm /532nm | |
| Energy | 600-1500mJ | |
| Pulse Width | <10ns | |
| YAG Bar | ¢6mm+¢7mm | |
| Pulse Characteristic | Multiple-Sequential Pulsing | |
| Repetition Rate | Up to 10 Hz | |
| Spot Size | 1-8mm | |
| 2940nm Er:YAG Fractional Laser | Applications | Wart and Nevus removal, Skin Resurfacing, Wrinkles and Fine lines, Photodamge |
| Spectrum | 2940nm | |
| Energy | 7x7 Pixel: 10-26mJ/microbeam; 9x9 Pixel: 5-15mJ/microbeam; | |
| 1540nm Er:Glass Fractional Laser | Applications | Skin resurfacing, Srugical scars, Strech marks, Acne Scar, Melasma, Whrinkle |
| Spectrum | 1540nm | |
| Energy | 10x10 Pixel: 30-70mJ/microbeam; 18x18 Pixel: 5-25mJ/microbeam; | |
| Long Pulse ND:YAG 1064nm | Applications | Permanent Hair Removal for all skin types, Leg Veins, Vascular lesion |
| Spectrum | 1064nm | |
| Energy Density | ¢3mm Tip: 10-500J/cm², ¢6mm Tip: 10-125J/cm², ¢9mm Tip: 10-55J/cm² | |
| Pulse Duration | 10-40ms | |
| Pulse Characteristic | Multiple-Sequential Pulsing,1-3 Pulse | |
| Repetition Rate | Up to 1Hz | |
| Spot Size | ¢3mm, ¢6mm, ¢9mm | |
