HS-411
Apolomed
INTRODUCTION
PRINCIPLE
The carbon dioxide (CO2) laser has been known to provide some of the most dramatic, age-defying results in the treatment of challenging skin imperfections including wrinkles, fine lines, photodamage, uneven skin tone and skin laxity, as well as in scar treatment, skin tags and benign tumors.
Using the power of the CO2 laser, the optimal mix of ablative and thermal effects and an array of applicators and treatment modes for highly tailored procedures. Apolomed's CO2 brings unparalleled precision and innovation to the field of dermatology and plastic surgery.
The CO2 laser is a highly flexible system for char-free tissue ablation, vaporization, excision, incision and coagulation of soft tissue. It allows physicians full control of treatment parameters, including level and depth of ablation and thermal control via pulse duration and mode of energy delivery. This versatility maximizes precision and treatment results while minimizing unnecessary tissue damage.
APPLICATION
Skin resurfacing (Rough skin, coarse pores, dark skin, light damage…)
Wrinkles (Crow's feet, head lines, frown line, Decree lines)
Pigmented nevus, epidermal pigmentation (freckles, etc.), epidermis (all kinds of warts) cutting
Scar Repair (acne scar, hypertrophic scar, burn scar, sunken scar, etc.)
Other applications (syringoma, condyloma, seborrheic, etc.)
Vaginal care (Vaginal wall tightening, collagen remodeling,thicker and more resilient, labium whitening)
ADVANTAGE
The CO2 laser HS-411 is produced by Apolomed, which is China's top medical aesthetic laser manufacturer. Operator can easily select the exact pulse energy, density, pulse width and scan area needed to get excellent treatments for ideal result.
USA RF TUBE laser emitter ensures longer lifetime and best energy distribution. 635nm infrared red aimming beam supported Different fractional size selectable and drawing function supported.
ULTRA SHORT PULSE duration makes safety & comfortable.
Irregualr treatment areas can be treated precisely and easily by using interface fingertip control.Drawing function for targeted area's intensive treatment.
SPECIFICATION
Model name | HS-411 | |||
Wavelength | 10600nm CO2 laser | |||
Laser power | 35W/55W | |||
Beam delivery | Articulated arm | |||
Function mode: Fractional/ Vaginal care | ||||
Energy | 1~300mJ/dot | |||
Pulse width | 0.1~50ms/dot | 0.1~10ms/dot | ||
Density | 25~3025PPA/cm2 (12level) | |||
Scan area | 20x20mm | |||
Shape | Square, Hexagon, Triangularm circular, freehand | |||
Pattern | Array, Random | |||
Function mode: Normal | ||||
Operation mode | CW/ Single Pulse/ Pulse/ S.Pulse/ U.Pulse | |||
Pulse repetition rate | S.Pulse: 2~500HZ U.Pulse: 2~1000HZ | |||
Pulse width | Pulse 5~500ms | Single pulse 1~500ms | S.Pulse 1~4ms | U.Pulse 100~900us |
Aiming beam | Diode 655nm (Red), adjustable brightness | |||
Operation interface | 8" true color touch screen | |||
Cooling system | Advanced air cooling system | |||
Power supply | AC100V or 230V, 50/60HZ | |||
Dimension | 50*45*113cm (L*W*H) | |||
Weight | 55Kg |
