Erbium Glass Nanometer Multiplatform Fractional Laser
You are here: Home » Devices » 需隐藏的分类 » Erbium Glass Nanometer Multiplatform Fractional Laser

Erbium Glass Nanometer Multiplatform Fractional Laser

Tattoo removal fractional erbium multi platform skin lasers system
Availability:

Product Description

HS-900 5


Multiplatform laser CE medical certified device HS-900

1064nm 2940nm 1540 long pulsed Er YAG ndyag laser
Specification
Handpiece
2940nm Er:YAG Fractional ablative laser
Energy
7x7 pixel:12~28mJ/microbeam
9x9 pixel:4~20mJ/microbeam
Beam expander:500~2000mJ
Zoom lens:500~200mJ
Pulse width
1.5ms,2.0ms,2.5ms


Handpiece
1540nm Er:glass fractional laser
Energy
10x10 pixel:30~70mJ/Microbeeam
18x18 pixel:5~25mJ/Microbeam
Pulse width
10ms,15ms


Handpiece
1064nm Long pulse Nd:yag laser
Pulse width
10~40ms
Repetition rate
0.5~1Hz
Energy density
φ9mm 1~110J/cm2
φ6mm 60~260J/cm2
φ9mm 150~500J/cm2


Handpiece
1064/532nm Q-switch Nd:YAG laser
Spot size
1~5mm
Pulse width
<10ns(single pulse)
Repetition rate
1~10Hz
Max.Energy
2400mJ(φ),4700mJ(φ6+φ7)


Handpiece
IPL/EPL
Spot size
15*50mm
Wavelength
420~1200nm
Filter
420/510/560/610/640~1200nm
690~950nm for SHR
IPL/EPL energy
10~60level


Handpiece
RF Monopolar or RF Bipolar
Output power
200W
RF tip
φ18mm,φ28mm,φ37mm


Operate interface
8" true color touch screen
Cooling
Advanced Air&TEC water cooling system
Power supply
AC 100V or 230V, 50/60Hz
Dimension
65*48*115cm(L*W*H)
Weight
72Kgs


Working principle:

2940nm Er:YAG Fractional Ablative Laser
2940nm Er:YAG laser was chosen due to its high ablation efficiency. Because of high absorption in target chromophore water at the
2940nm wavelength, the skin will be quicklt heated up and instantly peeled off with very little thermal energy.


1540nm Er:Glass Fractional Laser Nonablative Laser

Er:Glass laser system emits1540nm erium glass beam and split into a number of microscopic beams,producing tiny dots, or fractional
treatment zones within the selected target skin are,leaving the other skin area unaffected.


1064nm Long Pulse Nd:YAG Laser

The latest innovation in laser hair removal is to use the long pulse Nd:YAG laser, emitting a wavelength of 1064nm which safely
pass through the epidermis to the underlying strata

1064/532nm Q-Switched Nd Yag Laser

The special wavelength of YAG laser can penetrate skin of human body according to the theory and practice of "selective laser
decomposing",the instrument uses the laser-wave to break Chromatophore into pieces which can be naturally absorbed by the body.


Established in 2001, Shanghai Apolo Medical Technology Co., Ltd. Is with rich experience in the development, engineering and marketing of IPL, RF, body slimming beauty systems, micro'dermabrasion equipment, and a broad array of aesthetic laser such as: diode laser, Q-Switched ND Yag laser, erbium Yag, erbium glass and long pulse ND Yag laser etc.. Our products are used to provide a diverse range of treatment applications such as hair removal, skin rejuvenation, deep wrinkle removal, pigmentation removal, acne treatment, vascular treatment, scar reduction, sculpture, body slimming, tattoo removal and so on. Apolo equipments strictly in accordance with I S O 1 3 4 8 5.


 All our products are complied with Beauty CE and Medical CE certificate. Our top-end products had obtained F D A 5 1 0 K, Australia TGA, Brazil An'visa and many other different certificates. We have a strong distribution and channel network in more than 40 countries around the world such as in Europe, North America, South America, Southeast Asia, and Middle East. We aspire to keep growing and continue open to partners who are interested to grow with us and to add values to both parties. We commit to continuously transform ourselves to stay relevant as a market leader and engineered our products to provide the best value to our Partners and customers. Welcome to stay beauty with Apolo and lighting your life through technology.

HS-900 0416
