Erbium Professional Vascular Fractional Laser
You are here: Home » Devices » 需隐藏的分类 » Erbium Professional Vascular Fractional Laser

Erbium Professional Vascular Fractional Laser

8 IN 1 Long pulse 1064nm 2940nm Multifunction laser beauty equipment
Availability:

Product Description

Machine introduction:

Apolo multi-function platform can be adapted different handpieces all in one machine. With interchangable technology, the system can distinguish the handpieces automatically. There is no need to worry about misoperation because only the right corresponding system turn to active with its handpiece. The client can have part of or all available handpieces based on their actually needs.


HS-900 5


Technical specifications of Apolomed multifunction beauty machine

Er:YAG laser Handpiece 2940nm Er:YAG Fractional ablative laser
Energy 7x7 pixel:12~28mJ/microbeam
9x9 pixel:4~20mJ/microbeam
Beam expander:500~2000mJ
Zoom lens:500~200mJ
Pulse width 1.5ms,2.0ms,2.5ms
Er:Glass laser Handpiece 1540nm Er:glass fractional laser
Energy 10x10 pixel:30~70mJ/Microbeeam
18x18 pixel:5~25mJ/Microbeam
Pulse width 10ms,15ms
Long pulse laser Handpiece 1064nm Long pulse Nd:yag laser
Pulse width 10~40ms
Repetition rate 0.5~1Hz
Energy density φ9mm 1~110J/cm2
φ6mm 60~260J/cm2
φ9mm 150~500J/cm2
Q-Switch laser Handpiece 1064/532nm Q-switch Nd:YAG laser
Spot size 1~5mm
Pulse width <10ns(single pulse)
Repetition rate 1~10Hz
Max.Energy 2400mJ(φ),4700mJ(φ6+φ7)
IPL/EPL Handpiece IPL/EPL
Spot size 15*50mm
Wavelength 420~1200nm
Filter 420/510/560/610/640~1200nm
690~950nm for SHR
IPL/EPL energy 10~60level
RF Handpiece RF Monopolar or RF Bipolar
Output power 200W
RF tip φ18mm,φ28mm,φ37mm

Operate interface 8" true color touch screen
Cooling Advanced Air&TEC water cooling system
Power supply AC 100V or 230V, 50/60Hz
Dimension 65*48*115cm(L*W*H)
Weight 72Kgs

Multi Function Laser Platform advantages:

1. 8-in-1 multifunction system available,which combine different technoties in one basic unit.
2. Auto-detect interchangeable handpieces for option
3. Excellent cooling system with TEC water tank,Italy pump and high speed fans.
4. Multi-languages supported,meets requiremnets of global market.
5. Friendly touchable operate interface with standard mode and professional mode.
6. Interlock design ensure safety treatment environment.
7. Mudularized design for convenienet maintenance.
8. USB and IC card function supported.


Applications:

IPL applications:
uSkin care and rejuvenation
uPermanent hair removal
uVascular treatment
uDispel epidermal pigmentation
uDispel the spots and freckles
uAcne removal
uSkin lifting

EPL applications:
uSkin care and rejuvenation
uPermanent hair removal
uVascular treatment
uDispel epidermal pigmentation
uDispel the spots and freckles
uAcne removal
uSkin lifting
uWrinkle removal
Bipolar RF applications:
uSkin Tightening
uWrinkle Removal
uMake the pore contracted
uDeep wrinkle removal
uImprove the skin-metabolism
uAlleviate Oily Acne, eye pouch
Monopolar RF applications:
uSculpture
uCellulite skin treatment
uSkin tightening
uMake the pore contracted
uDeep wrinkle removal
uImprove the skin-metabolism
Q-switch Nd:Yag laser:
uEmbroidered eyebrow removal
uRemove soak lip and lip line                  uTattoo and tattoo wound removal
uPigmented Nevus treatment
uSeborrheic Keratosis treatment

Long pulse Nd:Yag laser:
uPermanent Hair Removal for all skin types
uLeg Veins and Telangiectasia
uVascular lesion
uWrinkle Removal

1540nm Er:Glass laser:
uSkin resurfacing
uSurgical scar, acne scar treatment
uStrech marks
uMelasma removal
uDeep wrinkle/ fine lines removal
2940nm Er:Yag laser:
uWart and Nevus removal
uSkin Resurfacing
uWrinkles and Fine lines
uPhotodamge
uTexture Irregularity
Er yag er glass 1064 long pulse qs laser ipl epl rf laser beauty equipment
