Product Description
Machine introduction:
Apolo multi-function platform can be adapted different handpieces all in one machine. With interchangable technology, the system can distinguish the handpieces automatically. There is no need to worry about misoperation because only the right corresponding system turn to active with its handpiece. The client can have part of or all available handpieces based on their actually needs.
Technical specifications of Apolomed multifunction beauty machine
| Er:YAG laser Handpiece | 2940nm Er:YAG Fractional ablative laser |
| Energy | 7x7 pixel:12~28mJ/microbeam |
| 9x9 pixel:4~20mJ/microbeam | |
| Beam expander:500~2000mJ | |
| Zoom lens:500~200mJ | |
| Pulse width | 1.5ms,2.0ms,2.5ms |
| Er:Glass laser Handpiece | 1540nm Er:glass fractional laser |
| Energy | 10x10 pixel:30~70mJ/Microbeeam |
| 18x18 pixel:5~25mJ/Microbeam | |
| Pulse width | 10ms,15ms |
| Long pulse laser Handpiece | 1064nm Long pulse Nd:yag laser |
| Pulse width | 10~40ms |
| Repetition rate | 0.5~1Hz |
| Energy density | φ9mm 1~110J/cm2 |
| φ6mm 60~260J/cm2 | |
| φ9mm 150~500J/cm2 |
| Q-Switch laser Handpiece | 1064/532nm Q-switch Nd:YAG laser |
| Spot size | 1~5mm |
| Pulse width | <10ns(single pulse) |
| Repetition rate | 1~10Hz |
| Max.Energy | 2400mJ(φ),4700mJ(φ6+φ7) |
| IPL/EPL Handpiece | IPL/EPL |
| Spot size | 15*50mm |
| Wavelength | 420~1200nm |
| Filter | 420/510/560/610/640~1200nm |
| 690~950nm for SHR | |
| IPL/EPL energy | 10~60level |
| RF Handpiece | RF Monopolar or RF Bipolar |
| Output power | 200W |
| RF tip | φ18mm,φ28mm,φ37mm |
| Operate interface | 8" true color touch screen |
| Cooling | Advanced Air&TEC water cooling system |
| Power supply | AC 100V or 230V, 50/60Hz |
| Dimension | 65*48*115cm(L*W*H) |
| Weight | 72Kgs |
Multi Function Laser Platform advantages:
1. 8-in-1 multifunction system available,which combine different technoties in one basic unit.
2. Auto-detect interchangeable handpieces for option
3. Excellent cooling system with TEC water tank,Italy pump and high speed fans.
4. Multi-languages supported,meets requiremnets of global market.
5. Friendly touchable operate interface with standard mode and professional mode.
6. Interlock design ensure safety treatment environment.
7. Mudularized design for convenienet maintenance.
8. USB and IC card function supported.
Applications：
IPL applications: | EPL applications: uSkin care and rejuvenation uPermanent hair removal uVascular treatment uDispel epidermal pigmentation uDispel the spots and freckles uAcne removal uSkin lifting uWrinkle removal |
| Bipolar RF applications: uSkin Tightening uWrinkle Removal uMake the pore contracted uDeep wrinkle removal uImprove the skin-metabolism uAlleviate Oily Acne, eye pouch | Monopolar RF applications: uSculpture uCellulite skin treatment uSkin tightening uMake the pore contracted uDeep wrinkle removal uImprove the skin-metabolism |
| Q-switch Nd:Yag laser: uEmbroidered eyebrow removal uRemove soak lip and lip line uTattoo and tattoo wound removal uPigmented Nevus treatment uSeborrheic Keratosis treatment | Long pulse Nd:Yag laser: |
| 1540nm Er:Glass laser: uSkin resurfacing uSurgical scar, acne scar treatment uStrech marks uMelasma removal uDeep wrinkle/ fine lines removal | 2940nm Er:Yag laser: uWart and Nevus removal uSkin Resurfacing uWrinkles and Fine lines uPhotodamge uTexture Irregularity |
