HS-230
Apolomed
Product Description
Principle of 980nm diode laser:
Based on theory of "selective laser photothermal", 980nm diode laser system uses specific 980nm wavelength to penetrate into skin for vasular treatment. The laser irradiation lesion, under laser irradiation, hemoglobin and red pigment capillaries to maximize absorption of laser energy, solidification occurs, blocking blood vessels, capillaries shrink, leading to intravascular coagulation, finally metabolic degradation. Due to the specific 980nm wavelength of the laser, it assures normal intact skin tissue architecture in the greatest degree during the vascular treatment and also ensures a good therapeutic effect without damaging superfacial skin.
Applications of 980nm diode laser:
Vascular lesions
Proliferative lesion
Spider veins
Liner angitelectasis
Cherry angiomasA Gold standard in hair removing
Before and After:
Veins removal treatment by 980nm diode laser:
Specifications
Specifications of medical portable 980nm vascular removal diode laser
| Vascular laser model | HS-890 |
| Wavelength | Diode laser 980nm |
| Laser output power | 15W or 30W |
| Output modes | CW, Single or Repeat pulses |
| Pulse width | 5-400ms |
| Repetition rate | 1~50HZ |
| Transmission system | Fiber of 300um with SMA 905 connector |
| Operate Interface | 8 inch touch screen |
| Warranty | Technical support forever |
| Voltage | AC 100V or 230V, 50/60HZ |
| Demension | 28*27*37cm (L*W*H) |
| Weight | 8Kgs |
Advantages of 980nm diode laser spider vein removal machine:
1. The advanced laser technology for red blood veins/vascular/spider veins removal in contrast with high frequency in the market.
2. 15 or 30W energy to satisfy different requirements.
3. Three modes: CW Pulse, Repeat Pulse and Single for optional.
4. Short time operation, no injury, no bleeding, no burning, redness or scar.
5. The obvious effectiveness: Only one or two treatments are required
6. Output power calibration at end of fiber
